Published 1/2023
Created by Subir Maity
MP4 | Video: h264, 1280×720 | Audio: AAC, 44.1 KHz, 2 Ch
Genre: eLearning | Language: English | Duration: 24 Lectures ( 2h 47m ) | Size: 696 MB
Learn Theory of OPAMP circuits and their analysis, 555 timer , Active filters, oscillators.
What you’ll learn
Understanding the basic characteristics of Operational Amplifier, 555 timer, VCO, active filters and oscillators.
Analysis of different OPAMP circuits such as adder, subtractor, differentiator etc.
Understanding the operation of filters, oscillators and other waveform generators and 555 timer.
Will be able to design analog circuits using opamp and other linear ICs.
Requirements
Basic idea about circuit analysis such as KCL, KVL, loop analysis etc.
Description
OPAMP and Linear ICs are essential parts of Analog Electronic Circuits. This course covers the fundamentals of OPAMP, OPAMP circuits, and other linear ICs. This course is suitable for diploma, undergraduate students, and electronic hobbyists interested to learn and design OPAMP-based circuits. This course may be a fundamental step to learning the essential theories to solve numerical important for different competitive exams, GATE, and PSUs for Indian students.———–Topics Covered (till now)———1. Operational Amplifier (OPAMP) introduction2. Pin diagram description3. Block diagram of OPAMP and a brief description of each block.4. OPAMP circuits: inverting and non-inverting amplifier5. Concept of virtual ground, voltage follower6. Adder, subtractor, and their analysis7. Differentiator and integrator: Ideal and practical9. Active filters: 1st and 2nd order filter (Butterworth) design techniques, frequency response.10. Oscillators (RC phase shift and Wien Bridge) with complete derivations.11. 555 Timer, Astable and Monostable operation, detailed derivation with internal circuits, and application of monostable and stable mode12. Comparators, Schmitt trigger, Zero crossing detector, Square and triangular wave generator using OPAMPTopics to be included shortly:13. Voltage regulator: Fixed and adjustable14. Voltage-controlled oscillators, Phase Locked loop: Brief idea and working mechanism15. Voltage to current and current to voltage converter16. Sample and Hold circuits17: Precision rectifier18: LC oscillators (Hartley and Colpitt Oscillator)19. Instrumentation amplifier and its analysis20: Digital to analog converter21. Problem practice 22. Quiz and assignments23. Sample questions.
Who this course is for
Beginners, undergraduate students those who interested to learn analog electronic circuits, operational amplifiers and circuit analysis.
