Linknode MapRelate 4.1.25.0108

MapRelate 是 Autodesk® AutoCAD® 的 GIS 数据导入器。

MapRelate 提供直接从 AutoCAD 内部将这些数据转换为图形中的实体的功能，允许对它们进行编辑并保存到 DWG 文件中。MapRelate 采用数据源配置的概念，以最大程度地灵活地确定如何读取和解释 GIS 数据，并提供文本、块、折线和多边形选项，以及图层、线型和颜色覆盖。图形数据可以从整个数据源绘制，或者对于大型数据集，可以通过当前 CAD 视图进行过滤，以确保您只获取所需的 GIS 信息。

File size: 38.6 MB

MapRelate is a GIS data importer for Autodesk® AutoCAD®. Geospatial data is essential background or engineering base data, but is typically managed by GIS systems and therefore held in proprietary formats including ESRI SHP, MapInfo, and Oracle.

MapRelate provides the facility, directly from within AutoCAD, to translate this data into entities in your drawing, allowing them to be edited and saved into the DWG file. MapRelate works on a concept of datasource configuration to give maximum flexibility in determining how GIS data is read and interpreted with options for text, blocks, polylines and polygons with a layer, linetype and color overrides. Drawing data can be drawn from the whole datasource or, for large datasets, filtered by the current CAD view to ensuring that you are only getting the GIS information you need.

Autodesk AutoCAD
Version: 2025 , 2024 , 2023 , 2022
Autodesk AutoCAD Architecture
Version: 2025 , 2024 , 2023 , 2022
Autodesk® Civil 3D®
Version: 2025 , 2024 , 2023 , 2022
Autodesk AutoCAD Map 3D
Version: 2025 , 2024 , 2023 , 2022
