Proteus软件是英国Lab Center Electronics公司出版的EDA工具软件。它不仅具有其它EDA工具软件的仿真功能，还能仿真单片机及外围器件。它是目前比较好的仿真单片机及外围器件的工具。虽然目前国内推广刚起步，但已受到单片机爱好者、从事单片机教学的教师、致力于单片机开发应用的科技工作者的青睐。
Proteus是英国著名的EDA工具(仿真软件)，从原理图布图、代码调试到单片机与外围电路协同仿真，一键切换到PCB设计，真正实现了从概念到产品的完整设计。是目前世界上唯一将电路仿真软件、PCB设计软件和虚拟模型仿真软件三合一的设计平台，其处理器模型支持8051、HC11、PIC10/12/16/18/24/30/DsPIC33、AVR、ARM、8086和MSP430等，2010年又增加了Cortex和DSP系列处理器，并持续增加其他系列处理器模型。在编译方面，它也支持IAR、Keil和MPLAB等多种编译器。
Proteus combines ease of use with powerful features to help you design, test and layout professional PCBs like never before. With nearly 800 microcontroller variants ready for simulation straight from the schematic, one of the most intuitive professional PCB layout packages on the market and a world class shape based autorouter included as standard, Proteus Design Suite 8 delivers the complete software package for today and tomorrow’s engineers.
PCB Layout
Proteus PCB design seamlessly combines Schematic Capture and PCB layout to provide a powerful, integrated and easy to use suite of tools for professional PCB Design.
Visual Designer
Visual Designer for Arduino combines world class Proteus VSM simulation with a new flowchart engine to provide a truly integrated and intuitive development environment.
VSM Simulation
The Proteus Design Suite is wholly unique in offering the ability to co-simulate both high and low-level micro-controller code in the context of a mixed-mode SPICE circuit simulation.
What’s New in Proteus :
– This Version is a significant release in our PCB development schedule with three main areas of focus.
– First, we have introduced comprehensive support for automatic length matching on the PCB. Having configured tolerances and the serpentine shape the user can simply select the relevant tracks and then the invoke the match command from the context menu.
– We’ve also introduced a more formal layer stackup wizard where the build up of the physical PCB can be specified and then passed to the fab house. This allows the user to specifically define the drill passes (drill ranges) used in the board which for multi-layer boards in particular then allows us to provide intelligent via options during track placement.
Finally, we’ve re-written the design explorer module to enable :
– System wide support for Assembly Variants, allowing the user to create a product variant and specify the ‘fitted’ or ‘not fitted’ state of individual parts in that variant.
– More powerful search and filtering on the schematic, together with property replacement. This makes it fast and simple for example to change the package on all 10nF capacitors in the design.
– Progress on the ‘push-and-shove manual routing’ feature remains on target for beta testing at the end of the year.
– Meanwhile, on the Proteus VSM side, we are pleased to announce the completion of the popular STM32 ARM Cortex-M3 family, along with several new variants in the PIC microcontroller families and several new embedded peripheral models.
– Finally, we have added support for popular Arduino robot turtle simulation to the Visual Designer module.
Operating System:
Windows® 10, Windows® 8 / 8.1, Windows® 7
