PTC Creo EMX 13.0.2.0 for Creo 7.0 x64 2020 Multilanguage-0daytown

简化的模架设计

许多模具制造者依赖于 2D CAD 方法来设计模架。因此，PTC Creo Expert Moldbase Extension 提供了一个理想的解决方案。此软件基于过程并且易于学习，它使模具制造者能在熟悉的 2D 环境中工作，同时利用 3D 的所有强大功能和优点，从而显著地缩短了提前期。

功能和优势

通过由过程驱动的简单工作流自动完成模架设计和细化，从而加快设计速度
包含 N 种模架/组件（例如螺钉、顶杆、滑块、冷却接头）的供应商的库
自动顶杆、水线和接头功能，自动完成流道和水线检查
通过 3D 环境消除了许多错误，从而防止了昂贵的返工开销并缩短了周期时间
通过自动更新模具模型、绘图和电极减少了对重新设计的需求

x64 | Languages:Multilanguage | File Size: 326 MB

Description:
Creo Expert Moldbase Extension contains customized detailed packages of plates and individual elements of all leading suppliers with the requirements of the main
standards in this area.

When creating a model block, Creo Expert Moldbase Extension automatically generates an assembly drawing, specification and plate drawings with regard to the requirements of ESKD.

Shaping components can be created directly in Creo Expert Moldbase Extension or you can use shaping components created in the CreoTool Design module.

Creo Expert Moldbase Extension has a specialized graphical interface with a schematic two-dimensional view of both finished designs of model blocks and individual components. At the same time, you can create and use your own designs, components, types of used injection molding machines, and enter your suppliers in the database. The selection of the main parameters of the mold components is carried out in two-dimensional mode. If it is necessary to specify the placement parameters of one or another component, the designer refers to the three-dimensional structure. This approach greatly speeds up the mold design process.

As a rule, full-fledged three-dimensional models of the mold assembly with holes, slots, etc. made in the plates are formed in an automated mode. In this case, all the holes and grooves are dependent – when you remove a component for which these structural elements were made, they are also removed. When you change the size and location of components, these geometric constructs are automatically rebuilt.

Details:
Year / Date:2020
Version:13.0.0.0
Developer:PTC
Architecture:64bit
Interface language:Multilanguage
Tabletka:additional no tablet required
System requirements:Presence of Creo Parametric 7.0 with a crowbar from SSQ;
Additional information :How to connect EMX to installed Creo Parametric 7.0 – see readme_SSQ.txt

Password/解压密码0daydown
