Bentley AutoPIPE V8i (SELECTSeries 5) 09.06.00.19

AutoPIPE 是一款专用于管道应力分析的高级综合软件工具。其直观的建模环境和高级分析功能有助于提高工作效率，改进质量控制效果。通过与结构模型和三维模型集成，可以实现流畅的数据协同，带来业务增长。

AutoPIPE 具备全面的设计功能，包括高级分析功能（例如，集成了用于流程工业、电力、石油天然气、核能、地下、海上 FPSO 平台及海下管道领域的墙热渐变、流体瞬变、热弯曲或分层、地震反应光谱封装以及蒸汽释放分析）。此外，还提供核工业认证，使用户可进行核结构设计。这些认证包括：10CFR Part 50、10CFR 21 和 ASME NQA-1-2000。

AutoPIPE 朝着可扩展型产品方向进行开发和完善，它可以满足从事核电和火电、流程工厂和化工厂、海上 FPSO 平台和防浪竖管设计、防火系统、炼油厂、跨国油气管线、FRP 管道以及建筑服务管道等行业的公司需求。AutoPIPE 现已融合了 ASME、英国、欧洲、德国、日本、中国、API、NEMA、ANSI、ASCE、AISC、UBC 和 WRC 标准与设计限制。

AutoPIPE 可与所有的智能化三维 CAD 主流系统（如 AutoPLANT、PlantSpace、Intergraph PDS 和 Aveva PDMS）进行无与伦比的集成，可以轻松生成和自定义自动化智能轴测图。目前，项目组的任何成员都可以做出早期设计决策、查看所有模型和图形数据，还可以使用 ProjectWise Navigator 对 AutoPIPE 和 CAD 模型进行自动碰撞检查。另外，AutoPIPE Plus 新增 AutoPIPE Nozzle，更名为“AutoPIPE Advanced”。

AutoPIPE 是目前市场上唯一与 STAAD.Pro 集成的管道和结构分析解决方案。用户可在 STAAD.Pro 中创建一个结构模型，将其移到 Bentley AutoPIPE 中进行更逼真的集成管道和结构分析，接着在短短几分钟之内便可将最终的管道模型连同管道支撑载荷一起完全传送到 Bentley STAAD 模型中 — 真正实现结构和管道信息的“数据流转”！

Bentley AutoPIPE 允许用户快速、轻松地创建、修改和检查管道与结构模型及其结果，同时为其提供了静态和动态条件下（如温度、风、海浪、浮力、地震和瞬变载荷等）的高级线性和非线性分析功能。

 Bentley AutoPIPE V8i (SELECTSeries 5) 09.06.00.15 | 568.1 mb

Bentley Systems, Incorporated, the leading company dedicated to providing comprehensive software solutions for sustaining infrastructure, announced the release of Bentley AutoPIPE V8i (SELECTSeries 5) 09.06.00.15, a stand-alone, engineering application for the calculation of piping stresses, fatigue stresses, fluid transient, bowing or thermal transient analysis, flange or pipe support design, and equipment nozzle loading analysis under static and dynamic loading conditions.

AutoPIPE provides a comprehensive and advanced software tool specialized in pipe stress analysis. The intuitive modeling environment and the advanced analysis features provide for increased productivity and improved quality control. Fluent data collaboration can be obtained through the integration with structural and 3D models, providing an environment for increased business growth.

AutoPIPE provides comprehensive design including advanced analysis features such as integrated through wall thermal gradient, fluid transient, thermal bowing or stratification, seismic response spectra enveloping, and steam relief analyses for process, power, oil and gas, nuclear, underground, offshore FPSO platform, and subsea pipeline areas. Nuclear approved software allows users to design Class 1, 2, and 3 nuclear piping systems. Approvals include standards as 10CFR Part 50, 10CFR 21, and ASME NQA-1-2008/2009a.

New Features In AutoPIPE V8i (SELECTseries 5) v09.06.00.15: http://communities.bentley.com/

About Bentley Systems, Incorporated

Bentley is the global leader dedicated to providing architects, engineers, geospatial professionals, constructors, and owner-operators with comprehensive software solutions for sustaining infrastructure. Bentley Systems applies information mobility to improve asset performance by leveraging information modeling through integrated projects for intelligent infrastructure. Its solutions encompass the MicroStation platform for infrastructure design and modeling, the ProjectWise platform for infrastructure project team collaboration and work sharing, and the AssetWise platform for infrastructure asset operations – all supporting a broad portfolio of interoperable applications and complemented by worldwide professional services. Founded in 1984, Bentley has more than 3,000 colleagues in 50 countries, more than $500 million in annual revenues, and since 2003 has invested more than $1 billion in research, development, and acquisitions.

Name: Bentley AutoPIPE V8i
Version: (SELECTSeries 5) 09.06.00.15
Home: www.bentley.com
Interface: english
OS: Windows XP / Vista / Seven
Size: 568.1 mb
