MSC Simufact Additive 1.0.0

MSC Software公司发布了专为金属增材制造工艺开发的仿真软件“Simufact Additive”。在使用3D打印机制作金属模型时，该软件可考虑到造型过程中发生的热变形等的影响进行形状及支撑结构的设计。

据天工社了解，该软件除了可对造型中的热变形实施预测仿真以外，还具备与从打印床切断部件、去除支撑结构、热等静压（HIP）等工艺有关的功能。凭借这些功能，在生产阶段便无需反复尝试，可高效率实施造型，节省时间和成本。另外，MSC公司成今后还将为该软件配备热-结构耦合分析、温度履历管理、基于拓扑学优化的造型形状设计、支撑材料设计等功能模块。

仿真示例，切断支撑部后支架的变形

3D打印机在产品开发中运用得越来越多，但同时也存在故障导致造型中断、无法按照CAD给出的形状实施造型等问题。因此，MSC开始提供使用仿真技术来设计造型形状及支撑结构的解决方案，为解决这些问题提供支援。

另外，据悉此次这款软件是MSC旗下开展生产工艺仿真业务的德国Simufact Engineering以MSC的仿真技术为基础开发的。

MSC Simufact Additive 1.0.0 | 470.3 mb
Simufact Engineering, an MSC Software company and expert in manufacturing process simulation, has announced the launch of Simufact Additive, a ground-breaking new software solution for the simulation of metal additive manufacturing processes.

Simufact Additive is a powerful and scalable process simulation environment for ‘right first time’ optimization of laser powder bed fusion processes. Features include simulation of all the key AM process steps starting with ‘printing’ of the part; followed by heat treatment, cutting the part off the build plate and removal of support structures, plus heat and pressure combined processes (HIP). The initial release of Simufact Additive will predict the final distortion and residual stresses of metal 3D printed parts; future functional enhancements will introduce additional features.

The modelling is carried out using CAD data in an innovative and newly developed Graphical User Interface (GUI) environment aligned with the real process work flow. Simufact Additive offers an intuitive approach which starts with defining the general process by determining the part and support components through to definition of manufacturing parameters up to the analysis settings and ultimate results. The software helps to compensate the distortion, minimize residual stresses and optimize the process parameters.

The concept behind the software is that it lays the foundation for a wide variability and scalability through different levels of details. This includes both a fast mechanical method for the prediction of distortion and residual stresses up to a fully thermo-mechanically coupled transient analysis which will be released soon. This will determine the temperature history and derived properties like the microstructure. The properties of the final part are available for a subsequent structural simulations.

New Graphical User Interface (GUI) concept for AM Modelling
Simufact Additive comes with an intuitive and user-friendly GUI. The flexible GUI concept allows machine and application-specific dialogs aligned with the real process work flow. A meshing capability is included for the automatic and rapid discretization of even large and complex structures of any shape. The GUI is laid out to smoothly handle these meshes that can readily reach more than a million elements.
Collaboration with 3D printing machine supplier
Renishaw plc, a leading manufacturer of advanced metal AM systems, is the first 3D printing machine vendor to collaborate with Simufact in the common goal of an integrated approach. The aim is a fully simulation based optimization leading to the best quality build file. Initially, Renishaw’s QuantAM build preparation software will be coupled with Simufact process simulation software and enable data exchange, using QuantAM’s open API (application programming interface). The next step is to automatically set-up a simulation based on the build information and in return to display the simulation results in Renishaw’s QuantAM build preparation software. The first results of this collaboration will be published and showcased at the major European additive manufacturing show, Formnext 2016, Frankfurt, this November.

About Simufact Engineering

Simufact Engineering – an MSC Software company – is a globally operating software company based in Hamburg, Germany. We are providing software products and services for the design and optimization of manufacturing techniques by means of process simulation. Simufact has firmly established itself as one of the four globally leading expert companies in this field.

Product: MSC Simufact Additive
Version: 1.0.0.48378
Supported Architectures: 64bit
Website Home Page : http://www.simufact.com
Language: english, german
System Requirements: PC
Supported Operating Systems: Windows 7even / 8.x / 10
Size: 470.3 mb
