The Hydraulics and Hydrology development team is pleased to announce the availability of OpenFlows StormCAD 2024 (24.00.00.24). This update included new capabilities to help you be more successful with your hydraulics and hydrology modeling projects.
What’s New in OpenFlows StormCAD 2024 (24.00.00.24)
Key new capabilities of this release of Bentley OpenFlows StormCAD include:
– Query-based Active Topology
– Selection Set Groups
– Tool to measure length and area in Stand-alone
– Search feature in TreeViews (Scenarios, etc.) and ListView controls (Selection Sets, Contours, etc.)
– Constraint-based Design Improvement
. Design Inverts Only calculation type
. Design only for selected elements
. Catalog conduit design options
– Support for SWMM Type 5 pumps
– SWMM Control Curves
– Inlet calculations based on SWMM method
– Inlet import/export to EPA-SWMM format
– Support for manholes set as storage in SWMM import/export
– User Formula Time of Concentration support
– Support for channel link draining to catch basin with a Ditch inlet type for the GVF-Rational solver
– Wet well support in Critical Storm Analysis
– Link to Ideas Portal
– Graph series hover tooltips
– Model compatibility
– Stability enhancements and fixes to reported issues
With OpenFlows WorkSuite, you can confidently plan, design, and operate water systems of any complexity. OpenFlows technologies combine real-time intelligence with spatial analytics, delivering visibility and insights to ensure optimal real-world outcomes. Apply OpenFlows solutions to a wide array of water-related processes, including water distribution and analysis, sanitary and combined sewer management, and flood risk assessment and mitigation.
StormCAD is the first and only fully-dynamic, multi-platform (GIS, CAD, and Stand-Alone) sanitary and combined sewer modeling solution. With StormCAD 2024, you will analyze all sanitary and combined sewer system elements in one package and have the option of performing the analyses with the SWMM algorithm or our own implicit solution of the full Saint Venant equations. Simply put, StormCAD offers the most comprehensive solution available for optimizing Best Management Practice (BMP) designs and meeting sanitary sewer overflow (SSO) and combined sewer overflow (CSO) regulations.
In this video we demonstrate how Bentley OpenFlows storm and sewer products can run inside AutoCAD. When running your OpenFlows products inside AutoCAD, you have access to the full range of functionality available in AutoCAD, in addition to the hydraulic modeling capabilities available in stand-alone. Applicable products: StormCAD, CivilStorm, SewerCAD, SewerGEMS.
Bentley Systems, Inc. is the global leader dedicated to providing architects, engineers, constructors, and owner-operators with comprehensive architecture and engineering software solutions for sustaining infrastructure. Founded in 1984, Bentley has nearly 3,000 colleagues in more than 45 countries, $500 million in annual revenues, and, since 2001, has invested more than $1 billion in research, development, and acquisitions.
Owner: Bentley Systems Inc.
Product Name: OpenFlows StormCAD
Version: 2024 (24.00.00.24)
Supported Architectures: x64
Website Home Page : http://www.bentley.com
Languages Supported: english
System Requirements: Windows *
Size: 848.1 mb
