Archiframe 21 11 2014 for ARCHICAD 18

Archiframe 21 11 2014 for ARCHICAD 18 | 46MB

Turn Architects’ Plans into Complete Wooden Structures – Everything in a Single ARCHICAD Model
ArchiFrame is an add-on that extends ARCHICAD into a complete designing tool for wooden structures. ArchiFrame provides tools for wall framing,column and beam structures, intermediate floors and roof structures. With these tools it is possible to reshape planks and beams in any way to get the desired result. Everything is inside a single ARCHICAD file – including 3D model and 2D elevations with semi-automated layouts and listings. Individual planks can be hand manufactured using ArchiFrame dimension drawings and cut lists, or produced with CNC.
ArchiFrame
Bill of Materials, CNC and Prints
Framing in 3D and Elevations in 2D
Tools for Elements and Individual Planks etc.
Weatherboards
Trusses in 3D and in Element Elevations
2D Foundation Dimensions
