NI InstrumentStudio 2021 (21.0.0)-0daytown

InstrumentStudio是新一代交互式PXI软件。

InstrumentStudio可帮助您统一显示数据，将仪器配置导出到代码，并监测和调试您的自动测试系统。您可以使用大型高分辨率显示器在统一显示器上查看数据，然后捕获多仪器屏幕截图和测量结果。您还可保存项目级配置，以便针对特定的待测设备更轻松地重复进行测试，或将仪器配置导出到编程环境，以简化代码并保证测量相关性。您还可以同时使用代码和InstrumentStudio来监测和调试运行的测试应用程序。

NI InstrumentStudio 2021 (21.0.0) | 1.5 Gb

NI , the provider of a software-defined platform that helps accelerate the development and performance of automated test and automated measurement systems, announced the release of its InstrumentStudio 2021 software for NI PXI modular instruments.

InstrumentStudio 2021 – Date: April 2021

New Features
– Added new RFSG Signal Generator panel supporting interactive use and debugging using PXIe-5820, PXIe-5830, PXIe-5831, PXIe-5832, PXIe-5840, and PXIe-5841.
– Added support for the PXIe-4135(35W) and PXIe-4137(35W) source measure unit, newly supported in NI-DCPOWER 20.7.

InstrumentStudio improves the live, interactive use model for modular instruments and makes debugging while running tests more intuitive. Engineers in the aerospace, automotive and semiconductor industries benefit from a more effective workflow for test system development.

InstrumentStudio evolves the concept of single-instrument soft front panels into a unified, multi-instrument environment, so engineers can capture screenshots and measurement results in one view from their suite of instruments. InstrumentStudio can also save project-level configurations for specific devices under test that can be repurposed later or shared with colleagues. This efficiency is key for testing high-mix devices and provides test repeatability at a convenience to the engineer or technician.

At different stages in the product design cycle, test engineers often waste valuable time correlating measurements between similar tests that ultimately use different hardware. And in production test, engineers who need to debug on the manufacturing floor may invest in separate hardware either for monitoring their tests or debugging their automated test equipment.

InstrumentStudio addresses these challenges by exporting configuration files to programming environments that reproduce settings, thereby simplifying measurement correlation. Additionally, test engineers can monitor PXI instrument behavior by running InstrumentStudio while test sequences execute in parallel, streamlining the debug process. Through these seamless interactions with programming environments and test sequences, InstrumentStudio becomes an important part of a comprehensive software workflow and helps engineers maximize their investment in PXI instrumentation.

To meet demands like testing higher complexity DUTs and shorter timeframes, engineers need tools tailored to their needs that they can efficiently use through their workflow, helping them to meet their exact application requirements. InstrumentStudio is the latest addition to NI’s software-centric platform that features products tailored to needs within distinct stages of their workflow – products that have been adopted in whole or in part by more than 300,000 active users. With LabVIEW engineering system design software at its core and TestStand test management software handling overall execution, this workflow helps to improve the productivity of test and validation labs across many industries. Each piece of the workflow is also interoperable with third-party software to maximize code/IP reuse and draws on the LabVIEW Tools Network ecosystem of add-ons and tools for more application-specific requirements.

Since 1976, National Instruments has equipped engineers and scientists with tools that accelerate productivity, innovation and discovery. NI’s graphical system design approach to engineering provides an integrated software and hardware platform that speeds the development of any system needing measurement and control. The company’s long-term vision and focus on improving society through its technology supports the success of its customers, employees, suppliers and shareholders.

Product: NI InstrumentStudio
Version: 2021 (21.0.0)
Supported Architectures: x64
Website Home Page : http://www.ni.com
Language: english
System Requirements: PC *
Size: 1.5 Gb
