The Structural Products development team is pleased to announce the availability of RAM Connection CONNECT Edition V13 Update 7 Patch 1 (13.07.01.005) is the first fully integrated steel connection design and optimization application in the industry.
RAM Connection CE V13 Update 7 Patch 1 (13.07.01.005) Release Notes – Date: June 2022
Resolved Issues:
– AS Base plate calculating fasteners shear capacity when a shear lug was defined. This capacity is no longer considered when a lug is defined to resist the shear.
– AS Base plate shear lug weld showing a slightly different value than the one defined in the Connection Pad. There was an unnecessary unit transformation for the variable introducing rounding errors.
– IS Bolted end plate reporting zero capacities for a Class 4 Built-up beam sections. McRd is now properly calculate for all Built-up class sections.
– AISC Single angle connection glitch with the use of the eccentricity for the calculation of the flexural yielding and flexural rupture capacities of the angle leg at the support side. This is fixed now and both capacities are calculated properly,
– AS Directly welded plate reduction of the weld strength for compression load in the beam-to-gusset and column-to-gusset interfaces was fixed by effectively reducing the value for cases in which the HSS connector is not concentric.
– AS Angle cleat incorrect ae distance calculation for bolts to supported member capacity. This is fixed now and ae is calculated properly for all cases.
– AS and NZS column panel zone demands were not considering column limit states to determine the demands correctly.
– NZS base plate anchor design factor for tension was modified according to the latest 2019 amendment.
– AS Flange cover plate beam splice incorrect net area for inner plates. This is fixed now, and the net area is calculated correctly regardless the beam section shape.
RAM Connection can check or design connections in seconds. Whether you design connections or need to check connections designed by the shop, RAM Connection is the software for you. In just one low-cost package, you get for steel frame connections the AISC ASD and LRFD, AS 4100-1998, BS5950-1, CSA S16-14, EN1993-EC3, GB50017 and IS800 connection design and optimization for shear and moment connections, braced frame connections, splices, and horizontal bracing connections. For truss connections you get the tubular connections design according to the AISC and the HSS Connection Design Manual. Through its seamless integration with the RAM Structural System, RAM Elements, and STAAD.Pro, RAM Connection raises the bar to a new level of productivity. All data regarding member sizes, joint geometry, and forces are transferred directly from either the RAM Structural System, RAM Elements, or STAAD.Pro to RAM Connection.
Bentley Systems, Incorporated is the global leader dedicated to providing architects, engineers, constructors, and owner-operators with comprehensive architecture and engineering software solutions for sustaining infrastructure. Founded in 1984, Bentley has nearly 3,000 colleagues in more than 45 countries, $500 million in annual revenues, and, since 2001, has invested more than $1 billion in research, development, and acquisitions.
Product: RAM Connection
Version: CONNECT Edition V13 Update 7 Patch 1 (13.07.01.005)
Supported Architectures: x64
Website Home Page : http://www.bentley.com
Languages Supported: multilanguage
System Requirements: Windows *
Size: 784.9 mb
