产品设计工程师经常都会面对这样的烦琐工作：理解纸面的 2D 示意图，以敷设 3D 缆和管道。PTC Creo Schematics（以前称为 Pro/ENGINEER Routed Systems Designer）针对此问题提供了解决方法。这个将电气和机械系统文档化的完善、独立的 2D 示意图 CAD 软件还自动将数据传输到 PTC Creo 中，以进行 3D 布缆和布管设计。也可以利用旧的 Pro/DIAGRAM 示意图并驱动 3D CAD 设计。这消除了数据误解，从而确保了与示意图的逻辑一致性。
有关 PTC Creo 3D 布线功能的更多信息，请访问 PTC Creo Piping and Cabling Extension 数据表和 PTC Creo Elements/Direct Cabling。
功能和优势
- 迅速轻松地创建原理图设计，从而能获取完整的系统文档（不论有多复杂）
- 多种专业，包括针对以下图表的功能：布线、布管和液压示意图
- 经过优化，可利用经过测试的方法在 PTC Creo Parametric 中驱动 3D 布缆和布管的实现
- 驱动 PTC Creo Elements/Direct（以前称为 CoCreate）中的 3D 布缆，可节省时间和减少错误
- 多用户功能通过并行设计使得效率更高
- 整套图表绘制工具支持设计的重复使用和产品开发过程的自动执行
- eSimulate Lite 可帮助您使用可编程的电压和电流源在设计中模拟和分析电压容限。
File Size: 503 MB
Creo Schematics supports growth opportunities. Drive 3D routes from 2D schematic logic, virtually eliminating errors.
Create 2D schematic designs of routed systems
Creo Schematics is a comprehensive, stand-alone 2D diagramming solution for creating 2D schematic diagrams of routed systems such as cabling, piping, HVAC, and hydraulic systems. The software automates the creation of detailed 3D routed system designs from existing 2D schematics within Creo Parametric and Creo Elements/Direct. This saves time, reduces errors, and eliminates tedious manual processes by correctly interpreting 2D logic and transferring it accurately into 3D. It also improves product quality by capturing both electrical and mechanical design intelligence within a single digital model. Now, design professionals across multiple disciplines can streamline product development processes and collaborate more effectively.
Creo Schematics features and benefits
With Creo Schematics, you can
Create schematic designs for routed systems quickly and easily, including complete system documentation, regardless of complexity;
Capture electrical and mechanical design intelligence within a single digital model;
Improve product quality by improving collaboration among electrical and mechanical designers;
Automatically create detailed 3D routed system designs from 2D schematics within Creo Parametric, and reduce errors and speed up time to market; and
Preserve the value of existing 2D data in both Creo Parametric and Creo Elements/Direct 3D modeling environments.
