The PLAXIS development team is pleased to announce the availability of PLAXIS 2D/3D CONNECT Edition V22 Update 2 (22.02.00.1078). Perform advanced finite element or limit equilibrium analysis of soil and rock deformation and stability, as well as soil structure interaction, groundwater, and heat flow.
Compatibility notes: Due to the major changes in the material database and the unit system, PLAXIS 2D CONNECT Edition Version 22 will be installed alongside Version 21, instead of overwriting it. When opening PLAXIS 2D V21 projects with PLAXIS 2D V22, projects will automatically be saved as a converted copy with the _converted suffix and will require recalculation. When using non-SI-units, the mesh also needs to be regenerated. The PLAXIS 2D CONNECT Edition V21 projects will remain unchanged. Earlier versions of PLAXIS will not be able to open files saved in PLAXIS 2D V22.
New in PLAXIS 2D CONNECT Edition V22 Update 2 – Release: October 2022
Cable bolt element
Added cable bolt element and material type to simulate rock reinforcement like grouted cables or frictional/grouted bolts that work mostly in tension/compression. Material definition includes input of bond stiffness and bond strength parameters in line with rock engineering practice. Other capabilities include confining stress dependency and pre-stressing of the element.
Hoek-Brown model improvements
Added tension cut-off and tensile strength parameters to the material parameter input. Safety calculations for Hoek-Brown materials now correctly reduce the tensile strength as well, providing more realistic safety factors.
Simplification of polylines and polygons
Exported CAD files can contain many less relevant intermediate points and lines. Once imported into PLAXIS 2D, these dense geometries will result in overly fine meshes and will slow down. During the import of, for example, geological cross-sections coming from Leapfrog or CAD applications, users can now select the “reduce point density” option to reduce the number of points of polygons or polylines present in the imported file. By reducing the number of points during the import process, the user can optimize the imported geometry for numerical analysis.
Free field boundary improvements
The free field boundaries implementation has been updated for this release offering several improvements. Deformation patterns, particularly along the boundaries, are now consistent with those expected in a far field analysis and there is no longer a need to include drained material columns at the model boundaries when performing an undrained or a partially undrained analysis. Several validation exercises were developed to ensure that the response when using free field BCs is consistent with what is expected from theory of wave propagation, as well as obtained when using other BCs (e.g. tied degrees of freedom).
Removed Academic watermarks
For users of Academic licenses, PLAXIS no longer displays watermarks in Input and Output.
New in PLAXIS 3D CONNECT Edition V22 Update 2 – Release: October 2022
Hoek-Brown model improvements
Added tension cut-off and tensile strength parameters to the material parameter input. Safety calculations for Hoek-Brown materials now correctly reduce the tensile strength as well, providing more realistic safety factors.
Improved robustness of import and intersections
Components for the import and intersection capabilities in PLAXIS 3D have been upgraded, improving the robustness when dealing with imported geometry, applying the intersect and recluster command and the automatic intersection when moving to the Mesh mode. The robustness of importing triangulated surfaces via OBJ and STL file format was also improved.
Removed Academic watermarks
For users of Academic licenses, PLAXIS no longer displays watermarks in Input and Output.
PLAXIS 2D is a powerful and user friendly finite element package intended for two-dimensional analysis of deformation and stability in geotechnical engineering and rock mechanics. PLAXIS is used worldwide by top engineering companies and institutions in the civil and geotechnical engineering industry. Applications range from excavations, embankment and foundations to tunnelling, mining and reservoir geomechanics. PLAXIS is equipped with a broad range of advanced features to model a diverse range of geotechnical problems, all from within a single integrated software package. PLAXIS uses predefined structural elements and loading types in a CAD-like environment. This empowers the user with fast and efficient model creation, allowing more time to interpret the results.
PLAXIS 3D is a powerful and user friendly finite element package intended for three-dimensional analysis of deformation and stability in geotechnical engineering and rock mechanics. PLAXIS is used worldwide by top engineering companies and institutions in the civil and geotechnical engineering industry. Applications range from excavations, embankments and foundations to tunnelling, mining and reservoir geomechanics. PLAXIS 3D has advanced features to tackle modelling challenges in the most complex geotechnical projects, that cannot be solved with PLAXIS 2D. Finite element modelling in full 3D has never been easier with a range of CAD-like drawing tools and extrude, intersect, combine and array operations. It’s almost like sculpting.
Bentley Systems, Inc. is the global leader dedicated to providing architects, engineers, constructors, and owner-operators with comprehensive architecture and engineering software solutions for sustaining infrastructure. Founded in 1984, Bentley has nearly 3,000 colleagues in more than 45 countries, $500 million in annual revenues, and, since 2001, has invested more than $1 billion in research, development, and acquisitions.
Owner: Bentley Systems Inc.
Product Name: PLAXIS
Version: 2D/3D CONNECT Edition V22 Update 2 (22.02.00.1078)
Supported Architectures: x64
Website Home Page : http://www.plaxis.com
Languages Supported: english
System Requirements: Windows *
Size: 4.9 Gb
