FloEFD for PTC Creo is an application for modeling flow and heat transfer in liquids and gases in the PTC Creo Parametric environment.
FloEFD is fully integrated into the PTC Creo Parametric environment and uses solvers based on computational fluid dynamics (CFD) technology
Main advantages
Working directly with the model in the PTC Creo Parametric environment
There is no need to convert the geometry into another format, which often leads to a loss of quality. The stated task of calculating fluid dynamics and heat transfer is completely synchronized with the model at any time.
Minimization of efforts, and as a result, errors in the process of synchronizing the stated fluid dynamics problem and the model.
Automatic detection of changes in the model.
There is no need to “manually” construct geometry describing the area occupied by liquid/gas
Automatic detection of the area occupied by liquid/gas.
Uses the same graphical controls as other PTC Creo Parametric modules
Very easy to learn
Easy to use
Uses PTC Creo Parametric model tree.
Intuitive and fully interactive
Use of model elements selected in the graphic window/model tree when creating a project/processing results
Visualization of calculation results in the form of static and animated images directly in the graphic window
Support for exporting results to MS Excel, Word. Ability to play and record animation
Support for multi-configuration of the model
For effective multi-parameter research, the ability to clone projects and automatically launch a series of calculations are implemented.
Automated to reduce the number of cases when it is necessary to involve specialists in the field of fluid dynamics and heat transfer to analyze the formulation and calculation results
Reliable and fully automatic grid generator.
A unique turbulence and boundary layer model is used.
Automatic control of solution convergence.
Reliable and accurate numerical methods and physical models
Large set of physical models
Accurate solution
Ability to calculate very complex structures and physical phenomena.
Computational Fluid Dynamics (CFD) and allows you to analyze a wide range of complex problems, including
• Analysis of hydro-aerodynamics and heat transfer of two – and three-dimensional models
• Analysis of external and internal flow flows
• Analysis of steady and unsteady flow
• Flow of incompressible fluid and compressible gas , including a flammable mixture, at subsonic,
transonic, supersonic and hypersonic flow regimes
• Condensation of water vapor
• Calculation of relative air humidity in gas flows
• Flow of Non-Newtonian liquids (laminar flow mode only)
• Flow in a compressible fluid (liquid density depends on pressure)
• Flows in real gases
• Analysis Laminar , turbulent and unsteady flows
• Analysis of vortex flows and fans
• Analysis of flows with solid inclusions
• Analysis of heat transfer within and between liquids and solids
• Analysis of heat transfer within solids in the absence of flow
• Calculation of thermal contact resistance
• Calculation of electrical contact resistance
• Thermoelectric coolers
• Heat transfer by radiation
• Joule heating
• Flows with gravitational effects (also known as the buoyancy effect)
• Porous media
• Heat pipes
• Heat transfer in printed circuit boards
• Heat transfer in perforated plates
• Flow of aerosol flows
• Accounting for the roughness of bodies during flows
• Accounting for tangential motion of walls ( stirring and rotation)
• Flow in rotating devices
• Cavitation in liquid flows
• Combustion in gas mixtures
System requirements
– Microsoft Windows 10 Pro or Enterprise 64-bit (tested with v1909), Microsoft Windows 11 Pro 64 -bit (tested with v21H2)
– For solver: Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Microsoft Windows Server 2016,
Microsoft Windows Server 2019, Microsoft Windows Server 2016 with HPC Pack 2016, Microsoft Windows Server 2019 with HPC Pack 2019
– Microsoft Office 365, Microsoft Office 2019, Microsoft Office 2016, Microsoft Office 2013
– Ethernet network adapter
– Mouse or other pointing device
– 8 GB RAM minimum, more recommended
– 2 GB of free hard disk space, more required for simulation models
– Localized languages : French, German, Japanese, Korean, Simplified Chinese, Russian
