AutoPIPE Vessel CONNECT Edition V40 Update 7

Bentley Systems Inc. is pleased to announce the availability of AutoPIPE Vessel CONNECT Edition V40 Update 7 (v40.07.00.007). This software provides you with cost-effective and accurate design of pressure vessels, heat exchangers, tanks, and air coolers.

AutoPIPE Vessel CONNECT Edition V40 Update 7 (v40.07.00.007) Readme File:

The following outline identifies new features and enhancements which have been implemented and the major defects which have been fixed.

Enhancements

Codes/Standards Update
– Material Database Update:
. EN 12452;
. EN 458-2;
. EN 10025;
. EN 10028-3-4-5-6-7;
. EN 10207;
. EN 10216-3-5;
. EN 10217-7;
. EN 10222-3-4-5;
. EN 10269;
. EN 10272;
. EN 10273
– EN profile tables
. Euronorm 53-62; 19-57; 56-77; 24-62
Legs Support
– CODAP C.9.9: Design of Leg support (new paragraph Ed. 06/14).
Skirt Support
– Local load analysis for skirt to compression ring (anchor) connection.
Drawings
– Added additional dimensioning sketches for TEMA types AKT / BKU Shell and Tube Heat Exchangers.
User Interface
– Corrosion value by chamber used as default value for corrosion.
Expansion joint design based on Finite Element Analysis (FEA), in accordance with TEMA 9th edition, including stress linearization (based on ASME Sec. VIII, Div. 2, Part 5) and verification with ASME code allowable stresses, available on 64-bit OS only [ Technology Preview ]
– CONNECT Project Configuration Settings (to manage project level settings through CONNECT) [ Technology Preview ]

Note: Technology Preview

Technology Previews provide users preliminary access to features currently in development and not QA certified and therefore not yet ready for production. These features are provided at no additional charge to promote awareness of a feature or technology to be deployed in a future release. Users are encouraged to provide feedback and suggestions. To learn more about Technology Previews or to gain access, please create a Service Request (be sure to include “Technology Preview” in the Description field)

Defects

NOTE: Problems described below represent specific issues with specific test cases. It is difficult to succinctly describe a problem and how it impacted the specific test case. If you have any questions about the issues discussed in this report, please contact your technical support.

User Interface
#769087: Insertion of copy of component to create a tubesheet can corrupt the EMVD file.
#866788: Legs support data are not displayed.
#866895: Saddle weight is not properly calculated when angle = 150°.
#869582: Nozzle local loads filled from standard inverted data.
#871729: Gasket Metal ring joint data Not fully defined (warning message).
#875136: crash when support bolt material name is greater than 14 characters.
#876234: Component Dialog – changes in Material Tab are not saved.
#889204: Full Jacketed Vertical Vessel – lifting lugs are placed on the inner head.
Calculation
#854408: Nozzle flexibility doesn’t consider the self-reinforcing thickness.
#870945: ASME VIII 1-5 effective areas calculation.
#882596: CODAP/EN tubesheet – recessed faces are not considered for the calculation of the minimum required thickness at the periphery.
#888571: Jacket Closure – the value of the Jacket space “j” for a Closure Bar is wrong calculated.
Material Database
#875964: Modulus of Elasticity issues (SA789-S31803; SA240-S31803).
Customizable Files
NOTE: Version 2.3
Config\Material.emdm (Material Database) (Updated)
Config\dimleg.xlsx (Legs Support) (Updated)
Config\dimsha.xlsx (Beam Shape) (Updated)

Product: AutoPIPE Vessel CONNECT Edition
Version: V40 Update 7 (Version 40.07.00.07)
Supported Architectures: 32bit / 64bit
Website Home Page : http://www.bentley.com
Language: english
System Requirements: PC
Supported Operating Systems: Windows 7even or newer
Size: 662.7 mb
