S-FRAME Structural Office R11

S-FRAME Structural Office R11 | 2.4 Gb

S-FRAME Software Inc., developer of structural engineering software solutions used by Structural and Civil Engineering Professionals worldwide, announced the release of S-FRAME Structural Office R11. This release one of the most extensive releases ever delivered by S-FRAME Software. R11 contains significant updates and new functionality to the existing product line of S-FRAME Analysis, S-STEEL Design, S-PAD Design, S-CONCRETE Design, S-LINE Design & S-CALC.

Key features in Structural Office R11 include:

S-FRAME Analysis:

– S-FRAME Analysis & S-STEEL Design are integrated in one common GUI environment
– Brand new Revit and Tekla Structures links that feature improvements in all aspects of the bi-directional capabilities including persistence, objects transferred, user interface, section mapping, and much more.
– A brand new DXF link featuring 3D visualization, fast rendering, ability to select what to import, automatic S-FRAME model group folder creation, and much more.
– For virtually all practical situations, model size limitation has been removed
– New Analysis types: for Quasi-Static, Pushover and Nonlinear Buckling
– New Elastic/Plastic link beam element, four new nonlinear hysteresis materials and support for partial releases and base isolators
– Further performance improvements to our solver engine in the areas of parallel processing and eigenvalue extraction (for both speed and accuracy)
– Implementation of the co-rotational beam element and two new convergence methods for solving the most challenging nonlinear structural problems

– S-STEEL Design supports steel design and code check for each stage in S-FRAME Analysis’ new Staged Construction module. S-STEEL & S-PAD design support the Hong Kong SUOS11 design code and include the latest CISC and AISC databases.
– S-CONCRETE Design supports concrete column design to Eurocode 2 – EN 1991-1-1-2004 and the ability to automatically perform code checking on a large number of columns, beams and shear walls in a batch mode.
– S-CALC 2013 supports new section properties and shapes, multiple languages and menu customization, plus a brand new DXF link.
– All products feature additional enhancements and are delivered with a new licensing system that offers users more flexibility and reliability.

S-FRAME Structural Office R11


About S-FRAME Software, Inc.

Since 1981, after introducing its first commercially available 2D analysis program, S-FRAME Software has led the industry in the development of easy-to-use, reliable, and innovative analysis and design software products trusted by structural and civil engineers worldwide working in a multitude of industries. S-FRAME’s Structural Office is a structural model management environment that enables users to design robust structures regardless of geometric complexity, material types, loading conditions, nonlinear effects, and design-code requirements. S-FRAME’s software products include: S-FRAME, S-STEEL, S-PAD, S-CALC, S-CONCRETE, S-LINE.

Name: S-FRAME Structural Office
Version: Release R11
Home: www.s-frame.com
Interface: english
OS: Windows XP / Vista / Seven / 8
Size: 2.4 Gb
