CAE分析者
为分析者开发的MeshFree软件，能够超越网格划分的局限性。分析者在做分析的时候，网格划分往往是不可避免的工作，网格划分的局限性会直接影响到整个分析。MeshFree软件利用结构化网格，工程师不需要考虑几何模型的复杂性，不需要网格划分，能够快速得到分析结果。
复杂的CAD模型不用简化就可以分析
FEM方法在分析复杂结构的时候，得到高质量的网格会很困难，所以会导致得不到准确的分析结果，但是MeshFree采用的是结构化网格，这种结构化网格会在结构曲面上自动形成边界，无需考虑CAD模型的复杂性，无需进行网格划分就能够得到理想的结果……………
File Size: 1.2 GB
MeshFree is a design and analysis cutting-edge technology developed as a joint project with Samsung Electronics. MeshFree performs finite element analysis on the original CAD model without need for meshing or defeaturing. MeshFree frees you from all the difficulties of today’s design and analysis software.
midasNFX is an integrated finite element analysis program for structural, CFD simulation and optimization design. It provides efficient and accurate analysis together with an integrated pre-post processor, developed by senior mechanical engineers with over 20 years of CAE software development expertise.
Within its highly interactive and visual environment, users have access to a variety of practical tools which can help to build, edit and manipulate CAE models. For 2D and 3D FE model creation, the users are free to use midas NFX’s powerful auto-meshers as well as extensive manual meshing tools.
midas NFX provides total solutions from high-end structural analysis functions such as contact analysis, nonlinear analysis, implicit / explicit dynamic analysis and fatigue analysis in addition to high-end fluid analysis functions such as moving mesh, free surface analysis and mass transfer analysis. Additionally midas NFX provides practical topology and size optimization considering static/dynamic analyses and manufacturing processes.
