Become an expert in PCB design and Electronics using EasyEDA software in a Professional way.
What you’ll learn
At the end of the course you will fully master EasyEDA, to be able to conduct out your own PCB designing projects, from scratch
You will become familiar with its interface, toolbars and basic commands, and you will master all the phases of the design, layout and configuration process
You will be able to design step by step PCB projects, understanding all the logic and ending with advanced practical examples
You will learn in a professional way the Designing Schematic and the Designing Schematic Components in EasyEDA from scratch
You will understand the fundamental concepts to be able to create and assign footprints to Shematic components, and creating PCB libraries in a professional way
You will learn the Placement and Routing in PCB Layout (also Routing using POLY method), and above all, understanding their interpretation
You will master all the BOM (Bill of Materials) and Gerber files generation and getting quotation of board from fabricator
You master the generation of Schematic component and Footprint of a Complex component
You will be able to practice the content learned in a practical way by following all the steps in the complete exercises and the 2 final projects
You will start with the basics and progressively carry out more complex steps until you reach an advanced level and absolute mastery at the end of the course
Requirements
Having basic notions of any PCB design software can help, but the course starts from scratch
Login to EasyEDA (if you don’t know how, don’t worry, it’s very easy and I’ll explain it to you in the course!)
A decent computer and of course, desire to learn!
Description
Become a PCB designer professional and learn one of employer’s most requested skills nowadays!This comprehensive course is designed so that students, engineers, electronics operators, researchers… can learn EasyEDA software from scratch to conduct PCB designs and electronic projects in a practical and professional way. Never mind if you have no experience in electronics or PCB, you will be equally capable of understanding everything and you will finish the course with total mastery of the subject.After several years working as an Engineer, I have realized that nowadays mastering EasyEDA for the electronic design and PCB is very necessary in engineering and other industrial applications. EasyEDA is the most popular cloud-based PCB software, and that is is why it is one of the leaders in the industry and its demand is increasing. Knowing how to use this software can give you many job opportunities and many economic benefits, especially in the world of engineering, architecture or design.The big problem has always been the complexity to perfectly understand the software it requires, since its absolute mastery is not easy. In this course I try to facilitate this entire learning and improvement process, so that you will be able to carry out and understand your own projects in a short time, thanks to the step-by-step and detailed examples of every concept.With more than 7 exclusive hours of video, this comprehensive course leaves no stone unturned! It includes both practical exercises and theoretical examples to master Easy EDA. The course will teach you PCB designing in a practical way, from scratch, and step by step.In the course, we’ll cover a wide variety of topics, including:Introduction to EasyEDA, PCB and course dynamicsLogin and general familiarization with the user interfaceComplete project setup and basic EasyEDA Commands and PreferencesDesigning Schematic and Designing Schematic Components in EasyEDA from scratchCreating and assigning Footprints of all schematic components and creating PCB libraries Placement and Routing of components in PCB Layout, and also Routing using POLY methodGenerating BOM and Gerber Files, getting quotation of board from fabricatorGenerating Schematic component and Footprint of a Complex componentDesigning from scratch 2 complete final projects to practice everything learnedMastery and application of absolutely ALL the functionalities of the softwarePractical exercises and much more!In other words, what I want is to contribute my grain of sand and teach you all those things that I would have liked to know in my beginnings and that nobody explained to me. In this way, you can learn to solve a wide variety of projects quickly and make versatile and complete use of PCB Design. And if that were not enough, you will get lifetime access to any class and I will be at your disposal to answer all the questions you want in the shortest possible time.Learning EasyEDA and PCB has never been easier. What are you waiting to join?
Overview
Section 1: The Complete Course of EasyEDA and PCB Design
Lecture 1 Introduction Guide of the Course
Lecture 2 Getting started with EasyEDA and knowing the GUI and basic settings of EasyEDA
Lecture 3 Designing Schematic in EasyEDA from Scratch
Lecture 4 Designing Schematic Components in EasyEDA
Lecture 5 Creating custom footprint and assigning it to schematic component
Lecture 6 Placing the components in PCB Layout as per Schematic diagram
Lecture 7 Routing of components in PCB Layout
Lecture 8 Routing of components in PCB Layout using POLY method
Lecture 9 Generating Bill of Materials and fabrication files (Gerber Files)
Lecture 10 Getting quotation of board from PCB Fabricator
Lecture 11 Generating Schematic component and Footprint of a Complex component
Lecture 12 Designing a complete EasyEDA project and practicing everything learned
Lecture 13 Schematic Designing of a complex Project in EasyEDA – Part 1
Lecture 14 Schematic Designing of a complex Project in EasyEDA – Part 2
Lecture 15 Overview of all the parts and Course closure
