Pulsonix 一款大名鼎鼎的PCB设计模拟软件, 最大特点是支持几乎所有流行的电路设计软件的文件格式,Netlist导入支持:
Pulsonix 电子自动化设计的产品范围为今天的电子工业设置了新的标准，易于模拟、易于使用的原理概述和PCB排版工具。来自电子产业专业的软件工程师团队的开发，Pulsonix已于今天成为21世纪最适应PCB设计中不断变化需求的高集成的电子电路设计软件
Pulsonix 8.0 is the latest edition and contains over 40 exciting new features and enhancements to our highly valued user base. Below is an overview of the major new features in this release.
– Footprint Rules
Footprint Rules provide a mechanism for automatically selecting PCB footprints where the Part has multiple footprint alternatives based on defined rules. This may be desirable for a variety of reasons, for example, to provide support for different soldering techniques or technologies. The Footprint Rules allow you to define the footprint type and rotation of the footprint selected for use based on the soldering or manufacturing technology being used.
Vias can be automatically added along, inside or outside of tracks and shapes.These can be used for shielding in RF or high speed designs for example. Via stitching into copper areas can also be achieved; Vias will be spaced, staggered or randomly added within a selected shape as an alternative to ‘pouring’ copper.This technique can be used for high-voltage applications.
Add breakout patterns (fanouts) to an existing BGA footprint in the footprint editor using a dialog driven interface without having to recreate it from scratch.This feature will save a huge amount of time where the footprint has been imported or created without the use of breakout patterns.
As a powerful addition to the Interactive High Speed suite, the Rules Spreadsheet enhances the head-up display by allowing you to view constraint Rules on each net with their lengths when editing, all in real time. Colour keys enable the rule and its current status to be clearly viewed in context, especially when a rule has been violated.
Routing multiple tracks across the design is made easy using the new Bus Routing option. Included within the Interactive High Speed suite, Bus routes are easily selected in the design from pads, vias, connections and tracks. Collections of Bus connections identified in the Schematic are carried through into the PCB design for easy selection.
Pulsonix Version 8.0 Update Notes: this
About WestDev Ltd.
WestDev is a dynamic company formed to provide a quality development and customer oriented service. WestDev’s staff are a mixture of top flight computer programmers with many years experience in main stream and leading edge EDA (Electronic Design Automation) CAD, and staff capable of providing a focused service to the customers.
WestDev purchased the exclusive rights to the Number One Systems name, stock and all product names including the simulators and ancillary products in November 1998 and are now trading as Number One Systems.
As a software development house WestDev are more than qualified to continue the development of all the Windows based products and to move them forward into the Millennium and beyond, thus ensuring a continued growth path, enabling us to grow with our customers own requirements as a ‘partnership’ with complete continuity.
Name: Pulsonix
Version: 8.0 Build 5536
Home: www.pulsonix.com
Interface: english
OS: Windows XP / Vista / Seven
Size: 316.5 mb
