Cadence Sigrity 2024是一款PCB电路设计仿真软件，可帮助PCB设计团队缩短设计周期的同时实现设计成本和性能的最优化。 独有的3D设计及分析环境，完美集成了Sigrity工具与CadenceAllegro技术，可提供效率更高、出错率更低的解决方案，大幅度缩短设计周期的同时、降低设计失误风险，进行补偿并提高高速电路的质量，需要对Allegro Sigrity软件方便的分析和纠正措施。
x64 | Languages:English | File Size: 8.21 GB
Description
Sigrity 2023 software for simulation and signal integrity in high-frequency circuits. With the advancement of digital processing technology, the need for faster processing has grown increasingly, Prdzashgrhayy that necessarily needs to work faster circuits with higher processing speeds and higher frequencies are located. By increasing the speed signals for accurate speed up the signals on routes that are mounted on boards PCB or boards laminated issues and new problems arises in the case of Field, gripped engineers will be events such as interference, distortion and noise and signal integrity at high frequencies cause to be subject to threats.
To minimize these threats, compensate them and increase the quality of high-speed circuits, needs analysis and corrective actions that the software Allegro Sigrity it is convenient for us. The software combines technology with design, editing and routing IC and PCB coordinate Cadence® Allegro® enables advanced analysis of both pre-layout and post-layout provides for users.
The software is designed to examine various scenarios in the initial phases allows accurate design and redesign minimized. This software supports reading and writing directly on the PCB and IC design of Allego’s database. Accurate simulator based on SPICE as well as built-solver for 2d and 3d extracts the user. The software also modeling the transistor-level input and output functions include power-aware IBIS 5.0 support.
……………
System Requirements
OS:Windows 10 (64-bit), Windows 2012 Server (All service packs), Windows 2016 Server (All service packs).
Note:Note: Clarity 3D Solver and Celsius with Hyper-V are not supported on Windows 7.
CPU:Intel® Core™ i7 4.30 GHz or AMD Ryzen™ 7 4.30 GHz with at least 4 cores
RAM:8 GB RAM / 64 GB RAM or higher
Space:50 GB free disk space / 500 GB free disk space SSD is recommended for primary operating system (OS) and simulation working directory
Internet:Microsoft® Internet Explorer® 9.0 or later
Display:1,024 x 768 display resolution with true color (16bit color) / Large monitor (or two) with Full HD resolution or higher
GPU:Dedicated graphics card with 1 GB video memory or higher
Password/解压密码www.tbtos.com
