The Bentley development team is pleased to announce the availability of Raceway and Cable Management CONNECT Edition Update 9 (10.09.01.18) . This integrated software system provides complete layout, routing, and material estimating functions in a single, integrated system and creates the framework for an effective workfl ow spanning all phases of the design, from initial concept to detailed layout and construction.
What’s New in Bentley Raceway and Cable Management CONNECT Edition Update 9 (10.09.01.18)
Redesigned Cable Manager now features a ribbon menu with a superior user experience
This new interface makes it faster and easier to find the most important commands and allows you to load large number of cables and perform operations faster and easier than before. Several new capabilities and optimizations have been introduced Cable Manager which include:
– Customize the data grid to display which fields you like and save different views that can be reloaded at any time.
– Group the cables by any field such as Source, Target, or Voltage Level and even define subgroups to organize and quickly find the cables you are interested in.
– Quickly apply filters to any field in the data grid to locate and focus on the cables you are interested in.
– New Flag field shows icons to indicate routing status, cable status, modification states, and warning states with a tooltip that explains their meaning.
– The Length field is now color coded to indicate whether the displayed length is the auto connected nearest orthogonal length (black), the routed length (green), or the 3D cable length (blue) which accounts for the cable bend radius.
– The functionality that was previously found within the Routing Manager sub dialog has now been merged into the main Cable Manager dialog bringing all the tools you need into one streamlined view.
AutoPlace Conduit tool can now generate conduits that directly touch the raceway trays and ladders
Previously when using the AutoPlace Conduit tool, there was a restriction which required the “Offset from Raceway” value to be greater than or equal to the “Virtual Connection” value, thus preventing the creation of conduits which could enter the side rail of a ladder raceway. This restriction has been removed allowing conduit to be placed as shown:
Cable Voltage Priorities
You can now set priority values for Cable Voltages in the Options > Cable Voltage Levels dialog. When a priority value is set for a voltage level, all cable types with that voltage level will inherit the priority.
OpenPlant Project Administrator (OPPA) can now perform a Dataset Upgrade
The ability to update a dataset is now included in OpenPlant Project Administrator (OPPA) so that we can update a dataset from one release to another. This is especially useful if you are only utilizing the design tools inside of OpenPlant Modeler.
Enhanced Raceway ID Tool allows you to quickly assign unique IDs to raceways without an existing ID
The Analyze Model command inside the Raceway ID tool will now retrieve all raceways without an ID assigned to them as separate segments rather than putting all parts under the same segment. Now when assigning raceway IDs with an increment each raceway will receive a unique ID.(as shown):
Immediately Assign Raceway IDs using the Raceway Generator
The ID Settings tab found in the Raceway Router are now available in the Raceway Generator enabling you to immediately generate new raceway parts including raceway IDs all in one easy operation that save you design time.
Configure User defined configurations Path
As a BRCM administrator, you can now define custom ID, Raceway, and Duct Bank spacer configurations and adjust a configuration variable to control where these configurations are saved making it more convenient for you to control who has rights to modify them. The variable, “BRCM_USER_DEFINED_CONFIGS” by default is set to the local user’s app data folder, but can be changed as you desire and is added to all delivered Workspace config files.
Updated Icons for specific tools makes it easier to identify their purpose
Updated a few of the tools icons in order to make them more recognizable. The tools that were updated include:
– 2D Extraction
– Cable List Import
– Cable Manager
– Create Section
– Delete 2D Extraction
– Equipment Import
– iModel Import
– Place Plane Section
– Raceway Labels
– Update Section
Equipment Additional Length property is now included in Reports
You can now include the Additional cable length field from Equipment in the following reports making it convenient to validate that you have entered accurate information for your equipment:
– Cable Route List 1
– Cable Route List 2
OBO cable basket (metric)
OBO cable basket (wire mesh) is now available and installed with the OBO metric dataset.
Corrected loading depth dimensions of existing cable ladders in the dataset
Many of our existing cable ladders did not have accurate loading width and depth dimensions specified because the height of the rungs may take away some loading depth which we didn’t previously account for. The datasets have now been upgraded to correct for this.
Schneider (metric) content now included in installer
The previous Schneider V8i content we had available for a separate download has now been updated for the CONNECT Edition and is available for install from the product installer.
Improved 3D Cable Performance
Now the speed of generating 3D cables is increased and reduced their footprint by replacing the solid elements with surface elements
Bentley Raceway and Cable Management provides an integrated software system that includes 3D design and modeling of raceways, cable trays, and conduit systems, as well as routing and managing the cables that run through these systems.
Design raceway and cable systems in one product using Bentley Raceway and Cable Management software. Save time and reduce cost with the first and only integrated system for layout, routing, and material estimating. Fast track your next project with automated workflows for conceptual and detailed design phases. Prevent construction delays by using an intelligent 3D model to spot clashes, ensure spacing, and get accurate take offs.
Bentley Systems is a software development company that supports the professional needs of those responsible for creating and managing the world’s infrastructure.
Product: Bentley Raceway and Cable Management
Version: CONNECT Edition Update 9 (10.09.01.18)
Supported Architectures: x64
Website Home Page : http://www.bentley.com
Languages Supported: english
System Requirements: PC *
Size: 8.4 GB
