The MicroStation product team is proud to announce the availability of Microstation 2023.00.01 (23.00.01.044) is the computer-aided design (CAD) software that users worldwide trust for creating precise 2D and 3D drawings for infrastructure projects. Apart from fixes in the detected issues, this version hosts a couple of noteworthy enhancements as well.
New in Microstation 2023.00.01 (23.00.01.044)
RealDWG 2024 Support
MicroStation now supports Reading/Writing and saving to the RealDWG 2024 file format.
Ability to Overwrite a cell definition while extracting a cell model
A new prompt is added to MicroStation 2023.00.01. When trying to update a cell definition with a newer version using the Extract cell Model dialogue, you will now be prompted to confirm the overwrite.
Ability to view the properties of the selected cell in the Cell Library dialog
The newly added Display the cell properties toggle in the Cell Library Dialog lets you view the properties of the selected cell in the properties pane.
Text Editor Enhancements:
– You will now see the Open Text Style Dialog icon in the Text Editor Window to open the Text Styles dialogue.
– Insert Stacked Fraction Dialog tool icon is now available in the Text Editor Window. The Insert Stacked Fraction tool setting window is now adjusted to display the full value of the entered fractions.
– The Text Editor Window will now open at full width to show all the available tools in the dialogue.
– A new check box is added in the User Preferences, Text Category. When toggled On, it allows you to set or change the highlight color of the text in the Text Editor window.
The following changes are made to the Web Feature Service (WFS) based on user feedback:
– You can now query and refresh instead of a one-off import.GIs data is tagged as context data and can be cleared in a click if need be.
– Connection management: There is no longer a limit of one connection, there can be multiple connections. They are saved in the design file and can be edited.
– Since OGC WFS does not define symbolization for elements, element templates are created for each feature, they can be edited and used for creating custom symbolization.
– Feature services UX enhancements: There is now a single dialogue for all feature services.
Web Map Service (WMS) version 1.3
MicroStation now supports Open Geospatial Consortium Web Map service 1.3.
(Technology Preview) Ability to Place Item type text as a Single Text node or Separate Text nodes
You can now place the Item Type text as a Single or Separate text node using the new toggle added to the Attach Item Dialog, Edit Item Dialog, and Clone Item Dialog. By default, the toggle is set to Single Text Node for all properties. If you choose to set a Separate text node then each property will be placed as a separate text node in the DGN.
(Technology Preview) Ability to Place Item Type Text from Explorer Dialog for a File or Model
While attaching the Item Type to a file or model from the Explorer dialogue, you can now place the Item Type Properties as Text. You can do so using the Display Text toggle in the Attach Item tool setting window.
(Technology Preview) Ability to set Default Text Level and Text Style in the Item Type dialog
Default Text Level and Default Text Style are the new fields added under the property definition in the Item Type Manager. With these fields, each property can be placed at different levels using different Text Styles through Item Type text placement. These fields apply only to the Item Types text placed as a Separate text node for each property.
With the Default Text Level, you can now place each property at the desired level available in the DGN. Also, you can place this property using different Text Styles available under the Default Text Style drop-down.
Features Moved from Technology Preview to Commercial Release
– Web Feature Service.
– Item Type propagation for Multi-line partial delete tool.
MicroStation is the only computer-aided design (CAD) software purpose-built for infrastructure design, helping architects and engineers like you bring their vision to life, present their designs to their clients, and deliver their projects to the community. MicroStation’s advanced parametric 3D modeling capabilities allow infrastructure professionals of any discipline to deliver data-driven, BIM-ready models. MicroStation and all Bentley BIM applications are built on the same comprehensive modeling platform. You therefore can easily progress your MicroStation work into discipline specific workflows with Bentley’s design and analytical modeling BIM applications. With this flexibility, each member of your project team has exactly the right application for the work they need to do. MicroStation 2023 is packed with new features, improved workflows, and several user experience enhancements, with focuses on a new access to geospatial features and maps, issue resolution improvements, increased data reporting, and user experience upgrades
This video series contains exercises intended to help a new MicroStation user become familiar with the MicroStation CONNECT Edition. This will be done from the point of view of a building designer or drafter working at a design firm, that is new to MicroStation, and has been awarded a design project that they will be involved with. During this course you will learn basic navigation of the MicroStation CONNECT user interface, creating and working with MicroStation design files, design file settings, and more.
Bentley Systems Inc. is the global leader dedicated to providing architects, engineers, constructors, and owner-operators with comprehensive architecture and engineering software solutions for sustaining infrastructure. Founded in 1984, Bentley has nearly 3,000 colleagues in more than 45 countries, $500 million in annual revenues, and, since 2001, has invested more than $1 billion in research, development, and acquisitions.
Owner: Bentley Systems Inc.
Product Name: MicroStation
Version: 2023.00.01 (23.00.01.044)
Supported Architectures: x64
Website Home Page : http://www.bentley.com
Languages Supported: english
System Requirements: Windows *
Size: 4.9 Gb
