DYNAFORM软件是美国ETA公司和LSTC公司联合开发的用于板料成形数值模拟的专用软件，是LS-DYNA求解器与ETA/FEMB前后处理器的完美结合，是当今流行的板料成形与模具设计的CAE工具之一。
Dynaform 软件基于有限元方法建立, 被用于模拟钣金成形工艺。Dynaform软件包含BSE、DFE、Formability三个大模块，几乎涵盖冲压模模面设计的所有要素，包括：定最佳冲压方向、坯料的设计、工艺补充面的设计、拉延筋的设计、凸凹模圆角设计、冲压速度的设置、压边力的设计、摩擦系数、切边线的求解、压力机吨位等。
Dynaform软件可应用于不同的领域，汽车、航空航天、家电、厨房卫生等行业。可以预测成形过程中板料的裂纹、起皱、减薄、划痕、回弹、成形刚度、表面质量，评估板料的成形性能，从而为板成形工艺及模具设计提供帮助。
Dynaform软件设置过程与实际生产过程一致，操作上手容易。来设计可以对冲压生产的全过程进行模拟：坯料在重力作用下的变形、压边圈闭合过程、拉延过程、切边回弹、回弹补偿、翻边、胀形、液压成形、弯管成形。
Dynaform软件适用的设备有：单动压力机、双动压力机、无压边压力机、螺旋压力机、锻锤、组合模具和特种锻压设备等。
x64 | File Size: 1.91 GB
Description
DYNAFORM is a simulation software solution, which allows organizations to bypass soft tooling, reducing overall tryout time, lowering costs, increasing productivity & providing complete confidence in die system design. It also allows for the evaluation of alternative and unconventional designs & materials.
DYNAFORM Modules
Blank Size Engineering (BSE)
BSE is widely used for estimating blank size, along with blank nesting for maximum material usage, scrap & piece price. The plug-in is used to predict thinning, thickening & also to generate a forming limit diagram (FLD).
Formability Simulation (FS)
FLD copyFS facilitates the rapid development & validation of single-station & progressive die designs. It uncovers hidden problem areas & enables designers to optimize designs based on accurate forming results.
Die Evaluation (D-Eval)
Since most tooling designs are done in a CAD environment, DYNAFORM’s D-Eval Module was specially created to support and analyze CAD based tooling and engineering designs.
Die System Analysis (DSA)dsiDSA efficiently predicts many stamping related concerns within the die production line. It is used to analyze scrap shedding/removal, die structural integrity & sheet metal transferring/handling.
Optimization Platform
This module helps users to go beyond identifying problem areas, by incorporating design optimization to improve performance and quality – reducing wrinkling, thinning and tearing.
System Requirements
-Operating System: Windows XP/Vista/7/8/8.1/10.
-Memory (RAM): 1 GB of RAM is required.
-Hard Disk Space: 700 MB of free space required.
-Processor: Intel Dual Core processor or later.
