集成热流体系统设计
FlowSimulator 是一款 3D 设计工具，可为 CAD 集成环境中的流体和热系统提供跨学科建模和优化。
系统级设计变得越来越重要，因为企业正在面临仿真复杂工作周期的挑战。需要采用 FlowSimulator 等快速软件解决方案对整个系统进行建模，包括对快速迭代概念建模，并理解系统仿真及系统在应用中的行为，例如旋转机械设计、电动车、风力涡轮机、换热器以及几乎任何包含热管理的应用。
FlowSimulator 初期由 GE Aviation 开发，用作飞机发动机的急流网络仿真器，以便仿真从跑道起飞到飞行和着陆为止的整个飞行周期在现实世界中的行为。自投入市场以来，该解决方案便用于简化各种复杂热系统应用的建模，包括医疗保健、机车和可再生能源。
Altair has released Flow Simulator 2024 is the single, unified fluid system design tool/platform for GE Aviation’s Thermal System design, Combustion, Lube/fuel systems, and externals teams. It is rooted in decades of practical usage and experience, with aerospace-quality level validation and verification.
Highlights
– Flow Network Grouping in the GUI
– Turbulator Friction and Heat Transfer in Tube Elements
– Rotating Surfaces in Tube Elements
Resolved Issues
– Added a limit for the heat flow from the thermal network convector to a flow chamber. The heat flow is limited by the heat capacity of the fluid. The flow chamber is not allowed to rise above the wall temperature for heating or fall below the wall temperature for cooling.
– Changed the standard tube element that allows it to converge for lower Mach numbers (<.000001).
– The vortex element automatic flow flag option uses improved logic to try the various flow calculation options. If a model has worse convergence in the 2024 release, try changing the vortex flow flag to the automatic option.
– GUI problems with the multi-edit of controller and FMU variables.
– GUI problem with built-in heat transfer coefficient units’ conversion.
– GUI problems with rotating and scaling images.
– Accumulators now get proper fluid when clicking Apply in the Material Manager.
Flow Simulator is a 3D design tool that provides interdisciplinary modeling and optimization for fluid and thermal systems within a CAD-integrated environment. System-level design has become increasingly critical as organizations are tasked with simulating complex duty cycles. Fast software solutions like Flow Simulator are needed to model an entire system, including rapid iteration concept modeling and understanding of system simulation and system behavior in applications such as rotating machinery design, electromobility, wind turbines, heat exchangers, and virtually anything that encompasses thermal management. Flow Simulator was originally developed by GE Aviation to serve as a fast flow network simulator for aircraft engines – simulating how an entire flight cycle would behave in the real world, from runway and take off to flight and landing. Since its inception, it has been used to simplify modeling for a variety of complex thermal systems applications, including healthcare, locomotives, and renewable energy.
Altair is a global technology company providing software and cloud solutions in the areas of simulation, high-performance computing (HPC), and artificial intelligence (AI). Altair enables organizations across broad industry segments to compete more effectively in a connected world while creating a more sustainable future.
Owner: Altair
Product Name: Flow Simulator
Version: 2024.x
Supported Architectures: x64
Website Home Page : http://www.altair.com
Languages Supported: english
System Requirements: Windows *
Size: 596.0 mb
