Engipedia 3d Room Tags 1.1.24.1102

File size: 5.0 MB

This Autodesk® Revit® add-in enhances spatial visualization by generating 3D tags and spatial volumes for Rooms and Spaces in the current model, with the ability to retrieve room data from linked models. The tool creates 3D tags displaying Room/Space names and numbers across all project phases and generates spatial volumes for a clear, detailed view of each room and space.

Ideal for 3D model reviews and coordination workflows, the add-in offers flexible management options. Users can select specific set of elements for tagging or volume creation, assign them to designated worksets and phases, and delete 3D tags, volumes, and associated filters. It also creates view filters for spatial volumes based on room/space names, improving data organization and visibility.

If a suitable tag family is not found, the add-in loads one automatically, ensuring smooth operation. Users can customize tag families as needed, as long as “Name” and “Number” instance text parameters are included.

The add-in also supports workflows with Autodesk® Navisworks® by embedding spatial information into the 3D model, enriching context during clash detection and design reviews. Additionally, users can clean models by removing all 3D tags, volumes, view filters, model filters, and shared parameters, keeping models streamlined.
