Solid Edge 2D Nesting 可用于生成预制材料，包括钣金、塑料、木材、布料和织物的二维切割优化排样。2D Nesting 让预制商可以更加高效地管理材料使用情况，从而节省预制时间和金钱。
2D 嵌套过程或者在一个切削平面上高效安排 2D 形状，与几十年前裁缝的做法很像。使用下一代嵌套算法优化的嵌套样式，大幅减少预制时间、废料和成本。
强大的嵌套功能，全面的控制能力
从开始到结束，2D Nesting 让创建优化嵌套变得快速而简单。
轻松完全控
控制任何切削技术或材料所需的设置，轻松选择零件量、片体尺寸和零件旋转。
与 Solid Edge 机械设计紧密融合
只需轻轻一点，就可以直接从 Solid Edge 启动选择要导入供嵌套的零件也迅速而简单。
可以处理多种文件格式
2D Nesting 支持 Solid Edge 钣金和零件文件（PSM 和 PAR）以及中性数据格式，包括 DXF 和 DWG，自动抽取展平图样数据。
减少废料
选择多种片体尺寸来创建最高效的嵌套，消除底边空白部分或是不完整片体。这些底边空白部分往往会造成废料，因为奇形怪状的剩余片体占据很大的工厂空间，并且常常会被弃用。
已对数控编程进行优化
嵌套可以发送至 Solid Edge CAM Pro 或导出到其他计算机辅助制造 (CAM) 系统，用于计算机数字控制 (CNC) 编程。
节省时间，避免转换
Solid Edge 环境中集成的往复功能可以节省时间并避免数据转换。
通过 Solid Edge 优化 2D 嵌套
Solid Edge 2D Nesting 利用最先进、最高效的嵌套引擎生成最佳布局，对钣金、木材等的二维切削进行优化。这些嵌套切削样式节省了创建产品常用 2D 形状的时间、废料和成本。
File Size: 147 MB
With Solid Edge 2D Nesting, generate optimized layouts for the two-dimensional cutting of fabrication materials, including sheet metal, plastic, wood, fabric and textiles. 2D Nesting saves fabricators time and money by allowing them to manage material use more effectively.
The process of 2D nesting, or the organization of 2D shapes efficiently on a single cutting plane, is much like processes dressmakers have used for decades. The optimized nesting patterns, created using a next-generation nesting algorithm, markedly reduce preparation time, waste and costs.
Capabilities
Powerful nesting, comprehensive control
From start to finish, 2D Nesting makes creating optimized nests quick and easy.
Complete control at your hands
Control all settings needed to meet the demands of any cutting technology or material, easily select part quantities, sheet sizes and part rotation.
Tightly integrated with Solid Edge Mechanical Design
Launch directly from Solid Edge with a single click. Selecting parts to import for nesting is quick and easy.
Work with multiple file formats
2D Nesting supports Solid Edge sheet metal and part files (PSM and PAR), as well as neutral data formats including DXF and DWG, automatically extracting flat pattern data.
Reduce wasted material
Select multiple sheet sizes to create the most efficient nest, eliminating tailings, or partial sheets. These tailings often result in wasted material, as the odd leftover sheets take up valuable shop space and often go unused.
Optimized for CNC Programming
The nests can be sent to Solid Edge CAM Pro or exported to another computer-aided manufacturing (CAM) system for computer numerical control (CNC) programming.
Save time, avoid translation
An integrated round trip within the Solid Edge environment saves time and avoids data translation.
