CADfix是针对至今还没有解决的数据转换的问题，它能自动转换并重新利用原有的数据。它能发现模棱两可、不一致、错乱的几何问题，工程师能看到问题的现象，并能通过CADfix进行修复。CADfix在可能的情况下支持全自动转换的方式，在自动方式不能完全解决问题的情况下CADfix另外还提供交互式可视化的诊断和修复工具。这种方式和其他”暗盒”式的转换器（PARASOLID-ACIS）或IGES和STEP形成鲜明对比，其他转换器不能告诉使用工程师手头上的数据有什么问题，而CADfix却可以。这样能节省大量的时间和金钱。

CADfix提供给用户分级式的自动、半自动工具，通过五级处理方式来处理模型数据，每一级处理既可以用用户化的自动”向导”来处理，也可以用交互式工具来处理。当自动”向导”处理方式可行的话，CADfix还提供批处理方式的工具来处理大量的模型数据。

CADfix提供多种输入输出转换格式：ACIS, Parasolid, IGES , STEP, STL, VDAFS, CATIA, CADDS5, ANSYS (report),Pro/Engineer PART,NX PART等等，为便于用户使用，CADfix另外提供CAE模型工具、模型转换工具、CAM应用工具。

ITI TranscenData CADfix 1.1GB

CADfix removes barriers that prevent the reuse of solid models by providing an extensive set of geometry manipulation tools for importing CAD/CAM/CAE data, repairing it, and exporting the data in the most suitable form for reuse in the downstream system.

Through a user-friendly Wizard interface, the geometry repair and preparation process ensures that the model is correctly defined and suitably flavored for the downstream application by detecting and repairing a range of CAD geometry issues. CADfix also offers model de-featuring utilities which are very popular with CAE analysis users who require automated de-featuring operations (i.e. joining or collapsing of short edges and small faces, removing fillets and rounds, removing holes, etc.).

CADfix is packaged as a desktop or server solution with extensible modular functionality dependent upon the source and target systems of the end user. The application may be integrated into PLM or workflow automation tools. CADfix also serves as a pre-processor for custom geometric translation, repair, de-featuring and meshing tools for proprietary, CAE-centric OEM applications.

CAD Translation, Healing & Repair

CADfix offers numerous translation, healing & repair advantages:
– Multiple CAD imports
– Batch processing
– Intelligent model quality diagnostics and repair
– Automatic processing Wizards
– User-controlled model defeaturing
– Interactive fixing tools
– Multiple CAD/CAE exports

The CADfix workflow accommodates novice, occasional and experienced users. Translations and repairs requiring manual intervention can be completed with minimal effort:
– Diagnostic results are explained and illustrated in clear, accessible language
– Problems are color-coded according to severity
– Users are guided through a choice of solutions
– Model diagnostics are automatically updated after each repair

CAD Reuse for CAE

CADfix offers CAE analysts the ability to automatically and interactively repair and transform CAD geometries prior to analysis. CADfix ensures that solid or surface models are robustly translated effectively into target systems. CADfix offers a full range of import and export functionality for pre-processing CAD data from native and neutral formats.
Master Model Driven FEA, CFD, EM Solutions

With ever shortening product design cycles, the emphasis on simulation tools to provide timely results to drive the design is greater than ever. This pressure dictates FEA, CFD and EM analysis being driven off the master model CAD data. CAD provides the geometry but a great deal of analysis time is still spent working with the geometry to prepare it for analysis.

CADfix for Geometric Exchange is uniquely positioned in the CAD to CAE data flow with its ability to read and write multiple geometric formats, repair and heal poor quality geometry and de-feature and simplify complex geometric definition. In the end, CAE analysts are starting with much more robust geometric definitions for their analytical needs.
